Built on Toshiba’s renowned industrial hardware platform driven by A-BRID offering a real‑time operating system with a Linux‑based OS, enabling advanced processing, seamless integration, and remote device intelligence - all within a single industrial printer, the BX820T introduces a smarter, connected approach to wide‑web labelling.
Key Features:
| BX820T | |
| Printing Method | Direct thermal / thermal transfer |
| Print Head Type/Alignment | Flat head edge / Centred |
| Resolution | TS02: 300 dpi (11.8 dots/mm) |
| Memory | 1 GB RAM, 8 GB ROM |
| Interface | USB 2.0 HS (USB host/HID support), LAN 10/100/1000 BaseT, RS232(1), WLAN 802.11ac/a/b/g/n/ax(1), Bluetooth 5.2(1), Expansion I/O(1) |
| Print Width/Length | 216.8mm / Batch: 15–1,368 mm, Cut: 38–1,368 mm |
| Print Speed | Max. 152.4 mm/second (6 ips) |
| Dimensions & Weight | 403 x 432 x 276 mm, 14.4 kg |
| Standard Ribbon Lengths | 300 m |
| Emulations | Auto-detection of TPCL, ZPL II, DPL, SBPL, IPL, PDF |
| Options | Swing cutter, Serial RS232, WLAN + Bluetooth, Expansion I/O, Real time clock, Cover damper |
