Thermal transfer wide-web industrial printer

Ideal for businesses transitioning from legacy systems, the BX620T supports thermal transfer printing with flat-head technology, tailored for 6” label formats.

Key Features:

  • Seamless integration with existing infrastructure.
  • Benefits from centred media alignment for consistent print quality across the label and from label to label.
  • Produces long-lasting labels suitable for pallet and drum labelling, automotive part identification and outdoor asset tagging.
  • Perfect for logistics, infrastructure and compliance labelling.


Key Specifications

  BX620T
Printing Method Direct thermal / thermal transfer
Print Head Type/Alignment Flat headedge / Centred
Resolution GS02: 203 dpi (8 dots/mm)
TS02: 305 dpi (12 dots/mm)
Memory 1 GB RAM, 8 GB ROM
Interface USB 2.0 HS (USB host/HID support), LAN 10/100/1000 BaseT, RS232(1), WLAN 802.11ac/a/b/g/n/ax(1), Bluetooth 5.2(1), Expansion I/O(1)
Print Width/Length 47–162 mm / Batch: 6–1,498 mm, Cut: 21.4–1,498 mm, Peel-off 21.4–1,496 mm
Print Speed Max. 305 mm/second (12 ips)
Dimensions & Weight 331 x 460 x 310 mm, 18.4 kg
Standard Ribbon Lengths 600 m
Emulations Auto-detection of TPCL, ZPL II, DPL, SBPL, IPL, PDF
Options Disc cutter, Peel-off, External media guide, Serial RS232, WLAN + Bluetooth, Expansion I/O, Real time clock (standard), Cover damper (standard)
